Riley 14/6 Stelvio II. (1931-34)

Carrying on from the success of the Stelvio, the Stelvio II was also built by the Weymann Coachbuilding Company at first, although some later models may have been produced in house by Riley. It was an elegant 4-light body, with a boot. The Stelvio was the only model that was produced throughout the lifespan of the 14/6 engine, and went on to be offered as the Stelvio III on the 15/6 chassis.
Despite having a unique 14S chassis number, there are simply too few Stelvios identified from old records to give a precise production figure. Between the Stelvio I and II it is thought that around 200-250 were built. It was previously thought that they used large batches of consecutive chassis, but again there are just too few known cars to be certain.

Chassis Type 14S


6cyl ohv
RAC Rating 13.5hp
Bore 60.3 Stroke 95.2
Firing Order 1, 5, 3, 6, 2, 4
Capacity 1633 cc


All Helical 4-speed gearbox.
Overall Gear Ratios:
2nd 13.5:1
3rd 8.06:1
Top gear 5.1:1
Reverse 19.36:1




Riley Continuous Cable with cam-operated shoes.
13" Drums.


Max speed 66.7mph
0-50 32secs
Fuel Consumption 19.3mpg


Wheelbase 10' (aprx 3040mm)
Track 4'8" (aprx 1400mm)
Length 13'9" (aprx 4230mm)
Width 5'6" (aprx 1670mm)
Wheels Wire 6-stud 3.0x20
Tyres 5.0x20
Fuel Tank 11galls.
Weight 26.75cwt (chassis only)
